Brokk 60II
The Brokk 60II is the perfect solution for safe, efficient demolition in very confined spaces. Its combination of small size and lightweight power works wonders in places where it was previously impossible to do mechanized demolition work. Compared to its older brothers, the Brokk 40 and Brokk 50, the 60II boosts productivity by 25% with a stronger breaker, faster movement, new control system and smaller profile. The low weight makes this demolition robot ideal for indoor work on weak floors, and it can be transported in an ordinary passenger elevator.
- The smallest remote-controlled demolition robot in the world
- Outperforms 5-10 people with jackhammers
- Brokk SmartRemote™
- Operates on just 16 A electrical fuse
- Access through even the smallest of doorways
Features
大容量润滑油罐
Brokk独有的遥控系统
日常保养-打开机盖
Protected components
- Hydraulic breaker in illustrations.
Load and stability diagram available on request. - BHB 55
Performance
- Slewing speed
- 6,5 sec/245°
- Transport speed, max.
- 2,5 km/h; 1.6 mph
- Climbing inclination, max.
- 30°
Hydraulic system
- Hydraulic system capacity
- 27 l; 7.1 US gal
- Pump type
- Gear pump with fixed displacement
- System pressure
- 18 MPa; 2 610 psi
- Pump flow max. 50Hz and 60Hz
- 22 l/min; 6 US gal/min
Power system
- Electric motor type
- ABB
- Motor rating*
- 5,5 kW
- Rated current*
- 14 A
- Power consumption*
- 0-6 kW
- Starting device
- Direct start
Control system
- Control type
- SmartRemote, portable control
- Signal code
- Digital
- Transfer
- Professional radio/Cable
- Range, radio
- Up to 300 m
Weight
- Machine weight**
- 500 kg; 1 102 lbs
- Recommend attachment weight
- 80 kg; 176 lbs
Noise level
- Sound power level LWA***
- 90 dB(A)
- Width min.
- 590 mm; 23.2 in
- Height min.
- 874 mm; 34.4 in
- Vertical reach (incl. breaker)
- 3100 mm; 122 in
- Horizontal reach (incl. breaker)
- 2500 mm; 98 in
*Valid for 400V/50Hz and 440V/60Hz
**Excluding options and attachment
***Measured according to directive 2000/14/EC, excl. attachment
