Brokk 300

Logoname
En imponerende trinn i vår evolusjon: Et helt nytt steg inn i vår styrke og vekt sammensetting.

VIL DU HA KATALOGEN VÅR? BESTIILL

Den helt nye BROKK 300 er et imponerende eksempel på hvor raskt Brokk-rivningsroboter utvikler seg for å imøtekomme industriens stadig økende krav. Denne maskinen vokste ut av de legendariske mellomstore Brokk-maskinene, men Brokk SmartPowerTM gjorde det mulig å ta et stort steg opp i kraft. Sammenlignet med sin forgjenger, bringer Brokk 300 en 40% sterkere slag og den bærer tyngre og kraftigere verktøy (BHB 455 og Darda CC580). Med imponerende kraft, rekkevidde og stabilitet er denne modellen skapt til å bli en annen legende i bransjen.

  • Enestående allsidig nedrivnings allsidighet
  • 37 kW Brokk SmartPowerTM elektrisk system
  • Brokk SmartDesignTM og SmartRemoteTM
  • Tyngre, kraftigere verktøy
  • Kompatibel med Brokk 280, vedlegg

Hydraulisk hammer illustrert.
Lastdiagram på forespørsel.
BHB 455

Ytelse

Svinghastighet
16 sec/360°
Transporthastighet, maks.
2,7 km/h; 1.7 mph
Transport Helling, maks.
30°

Hydraulikksystem

Hydraulikktank
95 l; 25 US gal
Pumpe type
Variabel aksialpumpe
Systemtrykk
18 MPa; 2 611 psi
Øket systemtrykk, redskap
23 MPa; 3 336 psi
Olje strøm 50Hz
100 l/min; 26 US gal/min
Olje strøm 60Hz
120 l/min; 32 US gal/min

Motor

Motor teknologi
SmartPower
Elektrisk motor
ABB
Motoreffekt*
37 kW
Anbefalt sikrings strørrelse*
63 A
Startmetode
Myk start/Direkte start

Styringssystem

Type
SmartSystem, Fjernkontroll
Signal
Digitalt
Overføring
Profesjonell radio/Kabel
Rekkevidde, radio
Opp til 300 m

Vekt

Maskin vekt**
3650 kg; 8047 lbs
Anbefalt redskapsvekt, maks.
500 kg; 1102 lbs

Støy

Støynivå LWA***
95 dB(A)

Bredde min.
1200 mm; 47.2 in
Høyde min.
1530 mm; 60.2 in
Rekkevidde vertikal, med hammer
6500 mm; 256 in
Rekkevidde horisontal, med hammer
6100 mm; 240 in

*Gjelder 400V/50Hz og 440V/60 Hz
**Uten tilvalg og redskap
***Målt iht. direktiv 2000/14/ec, eks redskap

Cylinder protection for cy 2 and cy 3

Cylinder protection for cy 2 and cy 3

Suitable for hot environments, act as heat- and impact protection.

Heat resistant hoses

Heat resistant hoses

Suitable for red hot applications.

Forced draft cooling of machine

Forced draft cooling of machine

Suitable for high ambient temperatures. Flushes cool air into electrical cabinet and cooler.

Forced draft cooling for breaker

Forced draft cooling for breaker

Suitable for red hot applications and flushes air through the breaker.

Steel pads

Steel pads

Suitable when machine is placed on very hot ground.

Airflushing through breaker

Airflushing through breaker

Prevents dust from entering breaker, suitable for upwards breaking and underwater breaking.

Waterspray

Waterspray

Sprays water when breaker is activated and binds dust efficiently.

Extra hydraulic function

Extra hydraulic function

Required for certain tools only.

Counterweight

Counterweight

Allows the use of extra heavy tools.

Cable reel

Cable reel

Spring loaded cable reel keeps track of the power cable.

Lifting eyes

Lifting eyes

Dedicated lifting eyes for easy connection. (Regular lifting points standard on all machines.)

Last ned PDF
Brokk cover

Brokk cover

Protects the Brokk machine during transport or storage.

Breakers

Brokk breakers are made for maximising your efficiency. There are breakers for each model, optimizing the power of your specifik Brokk machine. It hits harder and faster then other breakers on the market, still with less noise and vibrations.

Concrete crushers

Our crushers are just as scaringly effective as the look. Provides free rotation and has exchangeable tips. The larger crushers also has additional teeth and pulverizing pads.

Metal shears

The sane and easy way to cut pipes, bars, girders, profiles, structures etc. Different jaw sets, and replaceable cutting and breaking tips available for some models. Rotator with continuous rotation.

Buckets

With a bucket on your machine, your Brokk transforms to world’s most agile excavator, perfect for digging, loading, sorting & separation of material and debris.

Clamshell buckets

A variety of clamshell buckets transforms the Brokk to the perfect machine for loading, sorting & separation and transporting material and debris.

Multi Purpose Grapples

Brokk offers a broad range of grapples that helps you do the job more effective. The perfect tool for loading, sorting and separating debris (rock, concrete, wood, metal work). Rotator with continuous rotation.

Sorting & demolition grapples

These dedicated grapples are tailor-made tool for loading, sorting and separating debris (rock, concrete, wood, metal work). Rotator with continuous rotation.

Planers

Our effective BCP planers come with a valve for flow-control and motor protection, dust extraction system and mounting kit. The PCB Planers also have a swinging support rotation angle of 135°

Drilling

All-round attachment for drilling all types of holes in concrete, rock and compact soils. Blast holes at construction sites. Drilling in confined spaces, in all angels and directions.

Drum cutters

The Brokk drum cutters is ideal for tunneling, special foundation work, demolition, trenching and soil mixing. Suited for noise and vibration sensitive areas. They come complete with mounting kit and valves for flow-control and motor protection.

Beam Grapple

The Brokk beam grapple is perfect for tunneling and mining. Strong and robust. High and constant tilt force. Flexible and safe with variable support legs. Light-weight & big capacity.

Shotcrete

By connecting a high pressure pump machinery to this tool you are able do a variety of shotcrete work with your remote-controlled machine. Gunning and air pressure depends on concrete pump.

Cut off saw

Replaces hand-held equipment to cut steel work like door and window frames, conduits for electric cables. Leaves a nice clean cut and does not distort and twist the steel. Saw discs for different materials available.

Splitters

A light, powerful and versatile splitter with built-in booster for maximum power in a very slim design. Rotable with adjustable splitting direction. Different mounting options. Automatic lubrication.

Side angling device

The side angling device gives that extra working angle that can be useful in narrow space
