Brokk 110

Logoname
Stronger, smarter, tougher and more versatile. In an industry-leading compact size.

WANT OUR CATALOGUE? ORDER

The Brokk 110 is the new generation of demolition robots. With 15% more power than the Brokk 100 (and a whopping 50% more power than the Brokk 90), the new Brokk SmartPower™ electrical power system and the reinforced Brokk SmartDesign™, it’s built to face almost anything. It is extraordinarily versatile in tight spaces, with its industry-leading compact size. It folds up into a surprisingly compact package that can climb stairs, fit in an elevator and be carried on a small truck or trailer. It’s the perfect solution in a wide variety of residential, commercial and industrial environments. A demolition robot that’s stronger, smarter and tougher.

  • Most compact and powerful machine of its size
  • 19,5 kW Brokk SmartPowerTM electrical system
  • Brokk SmartDesignTM and SmartRemoteTM
  • Operates on both 16 A and 32 A fuses
  • Real 360 degree working radius

Hydraulic breaker in illustrations.
Load and stability diagram available on request.
BHB 155

Performance

Slewing speed
10 sec/360°
Transport speed, max.
2,5 km/h; 1.6 mph
Climbing inclination, max.
30°

Hydraulic system

Hydraulic system capacity
40 l; 10.6 US gal
Pump type
Variable load-sensing
System pressure
18,0 MPa; 2 611 psi
Pump flow 50Hz
54 l/min; 14 US gal/min
Pump flow 60Hz
65 l/min 17 US gal/min

Power system

Power technology
SmartPower
Electric motor type
ABB
Power*
19,5 kW
Recommended fuse size*
32 A
Minimum fuse size (reduced power)*
16 A
Starting device
Soft start/Direct start

Control system

Control type
SmartRemote, portable control
Signal code
Digital
Transfer
Professional radio/Cable
Range, radio
Up to 300 m

Weight

Machine weight**
990 kg; 2 183 lbs
Recommended attachment weight
160 kg; 353 lbs

Noise level

Sound power level LWA***
91 dB(A)

Width min.
780 mm; 30.7 in
Height min.
1147 mm; 45.2 in
Vertical reach (incl. breaker)
4300 mm; 169 in
Horizontal reach (incl. breaker)
3700 mm; 146 in

*Valid for 400V/50Hz and 440V/60Hz
**Excluding options and attachment
***Measured according to directive 2000/14/EC, excl. attachment

Extra Cylinder Protection

Extra Cylinder Protection

Provides impact protection for C2 and C3 and works as a heat shield when working in red hot environments.

Download PDF
Heat resistant hoses

Heat resistant hoses

Suitable for red hot applications.

Download PDF
Forced draft cooling for breaker

Forced draft cooling for breaker

Suitable for red hot applications and flushes air through the breaker.

Download PDF
Steel pads

Steel pads

Suitable when machine is placed on very hot ground.

Download PDF
Waterspray

Waterspray

Sprays water when breaker is activated and binds dust efficiently.

Download PDF
Air flushing for breaker

Air flushing for breaker

Air flushing prevents dust from entering the breaker, especially useful for upwards breaking and a must for underwater use.

Counterweight

Counterweight

Allows the use of extra heavy tools.

Download PDF
Lifting eyes

Lifting eyes

Dedicated lifting eyes for easy connection. (Regular lifting points standard on all machines.)

Download PDF
Extra hydraulic function

Extra hydraulic function

Required for certain tools only.

Download PDF
Brokk cover

Brokk cover

Protects the Brokk machine during transport or storage.

Breakers

Brokk’s hydraulic breakers are the most versatile and effective attachments for your Brokk robot

Concrete crushers

A concrete crushers allows you to do silent demolition with less noise, dust and vibration

Metal shears

Our wide range of metal shears allows you to cut steel of many different sizes

Buckets

Turn your Brokk robot into a flexible excavator, optimal for confined spaces.

Clamshell buckets

Brokk’s wide range of clamshell buckets transforms your Brokk robot into the perfect machine for sorting material and debris.

Multi Purpose Grapples

Make your work even more efficient with a multi purpose grapple from Brokk, the ideal attachment for loading, sorting, and separating debris.

Sorting & demolition grapples

Sorting and demolition grapples are tailor-made and ideal for soft demolition and stripping structures inside of buildings.

Planers

Brokk planers remove concrete, paint, asbestos, or other layers in a controlled manner up to a certain depth

Drilling

Drill holes in rock, concrete, or compact soil in open or limited spaces

Drum cutters

Brokk drum cutters are designed for trenching, demolition, and concrete surfaces

Cut off saw

Replace hand-held equipment with a Brokk cut off saw.

Side angling device

Give your Brokk hydraulic breaker that extra angle for extremely confined spaces.
