Brokk 170

Logoname
Upgrading the market-leading demolition robot with unbeatable power, new accessibility and smart, ergonomic design.

WANT OUR CATALOGUE? ORDER

If you liked the Brokk 160 you’ll love the BROKK 170. Taking the best from Brokk 160 and adding the full Brokk SmartConcept – the power of SmartPowerTM, the reliability of SmartDesignTM, the ergonomics and productivity of SmartRemoteTM – the Brokk 170 is the ultimate demolition robot for the construction industry. And don’t let the size fool you. This new, lightweight machine gives you 15 % more power, packs a mean wallop with the breaker and brutal force with the crusher. Still, it’s compact enough to get through standard door openings. A lean, mean demolition machine.

  • New benchmark in breaker and crusher performance
  • 24 kW Brokk SmartPowerTM electrical system
  • Brokk SmartDesignTM and SmartRemoteTM
  • Can operate on 32 A fuse (and of course 63 A)
  • Compatible with Brokk 160 attachments

Features

Big size grease container

Big size grease container

Brokk unique control system

Brokk unique control system

Daily maintenance - hoods on

Daily maintenance - hoods on

SmartPower™

SmartPower™

Hydraulic breaker in illustrations.
Load and stability diagram available on request.
BHB 205

Performance

Slewing speed
10 sec/360°
Transport speed, max.
2,1 km/h; 1.3 mph
Climbing inclination, max.
30°

Hydraulic system

Hydraulic system capacity
85 l; 22.5 US gal
Pump type
Variable load-sensing
System pressure
18 MPa; 2 611 psi
Increased pressure to attachment
25 MPa; 3 626 psi
Pump flow 50Hz
69 l/min; 18 US gal/min
Pump flow 60Hz
83 l/min; 21 US gal/min

Power system

Power technology
SmartPower
Electric motor type
ABB
Power*
24 kW
Recommended fuse size*
63 A
Starting device
Soft start/Direct start

Control system

Control type
SmartRemote, portable control
Signal code
Digital
Transfer
Professional radio/Cable
Range, radio
Up to 300 m

Weight

Machine weight**
1 600 kg; 3 527 lbs
Recommended attachment weight
270 kg; 595 lbs

Noise level

Sound power level LWA***
87 dB(A)

Width min.
780 mm; 30.7 in
Height min.
1254 in; 49.4 in
Vertical reach (incl. breaker)
4800 mm; 189 in
Horizontal reach (incl. breaker)
4400 mm; 173 in

*Valid for 400V/50Hz and och 440V/60Hz
**Excluding options and attachment
***Measured according to directive 2000/14/EC, excl. attachment

Cylinder protection for cy 2 and cy 3

Cylinder protection for cy 2 and cy 3

Suitable for hot environments, act as heat- and impact protection.

Download PDF
Dozer blades

Dozer blades

Allows for dozing of material.

Download PDF
Heat resistant hoses

Heat resistant hoses

Suitable for red hot applications.

Download PDF
Forced draft cooling of machine

Forced draft cooling of machine

Suitable for high ambient temperatures. Flushes cool air into electrical cabinet and cooler.

Download PDF
Forced draft cooling for breaker

Forced draft cooling for breaker

Suitable for red hot applications and flushes air through the breaker.

Download PDF
Steel pads

Steel pads

Suitable when machine is placed on very hot ground.

Download PDF
Airflushing through breaker

Airflushing through breaker

Prevents dust from entering breaker, suitable for upwards breaking and underwater breaking.

Waterspray

Waterspray

Sprays water when breaker is activated and binds dust efficiently.

Download PDF
Extra hydraulic function

Extra hydraulic function

Required for certain tools only.

Download PDF
Lifting eyes

Lifting eyes

Dedicated lifting eyes for easy connection. (Regular lifting points standard on all machines.)

Download PDF
Brokk cover

Brokk cover

Protects the Brokk machine during transport or storage.

Breakers

Brokk breakers are made for maximising your efficiency. There are breakers for each model, optimizing the power of your specifik Brokk machine. It hits harder and faster then other breakers on the market, still with less noise and vibrations.

Concrete crushers

Our crushers are just as scaringly effective as the look. Provides free rotation and has exchangeable tips. The larger crushers also has additional teeth and pulverizing pads.

Metal shears

The sane and easy way to cut pipes, bars, girders, profiles, structures etc. Different jaw sets, and replaceable cutting and breaking tips available for some models. Rotator with continuous rotation.

Buckets

With a bucket on your machine, your Brokk transforms to world’s most agile excavator, perfect for digging, loading, sorting & separation of material and debris.

Clamshell buckets

A variety of clamshell buckets transforms the Brokk to the perfect machine for loading, sorting & separation and transporting material and debris.

Multi Purpose Grapples

Brokk offers a broad range of grapples that helps you do the job more effective. The perfect tool for loading, sorting and separating debris (rock, concrete, wood, metal work). Rotator with continuous rotation.

Sorting & demolition grapples

These dedicated grapples are tailor-made tool for loading, sorting and separating debris (rock, concrete, wood, metal work). Rotator with continuous rotation.

Planers

Our effective BCP planers come with a valve for flow-control and motor protection, dust extraction system and mounting kit. The PCB Planers also have a swinging support rotation angle of 135°

Drilling

All-round attachment for drilling all types of holes in concrete, rock and compact soils. Blast holes at construction sites. Drilling in confined spaces, in all angels and directions.

Drum cutters

The Brokk drum cutters is ideal for tunneling, special foundation work, demolition, trenching and soil mixing. Suited for noise and vibration sensitive areas. They come complete with mounting kit and valves for flow-control and motor protection.

Cut off saw

Replaces hand-held equipment to cut steel work like door and window frames, conduits for electric cables. Leaves a nice clean cut and does not distort and twist the steel. Saw discs for different materials available.

Side angling device

The side angling device gives that extra working angle that can be useful in narrow space
