Brokk 200

Logoname
A muscle, reach and size ratio masterpiece. And now, this demolition robot also outsmarts the competition.

WANT OUR CATALOGUE? ORDER

Watch out, there’s a new weight class in town! Weighing only 2.1 tons, the Brokk 200 uses 27.5 kilowatts of Brokk SmartPower™ to carry attachments in a weight class higher than its size. Equipped with the breaker BHB 305 or the Darda CC480 concrete crusher, the Brokk 200 is unbeatable. A compact masterpiece with incredible strength and reach.

  • Brutal demolition power
  • Small footprint for its power and reach
  • 27.5 kW Brokk SmartPower™ electrical system
  • Built and optimized for heavy, high performance attachments

Features

Brokk unique control system

Brokk unique control system

Big size grease container

Big size grease container

SmartPower™

SmartPower™

Daily maintenance - hoods on

Daily maintenance - hoods on

Hydraulic breaker in illustrations.
Load and stability diagram available on request.
BHB 305

Performance

Slewing speed
10 sec/360°
Transport speed, max.
2.1 km/h; 1.3 mph
Climbing inclination, max.
30°

Hydraulic system

Hydraulic system capacity
85 l; 22.5 US gal
Pump type
Variable load-sensing
System pressure
18 MPa; 2 611 psi
System pressure, increased to attachment, max.
23 MPa; 3 336 psi
Pump flow 50Hz
85 l/min; 22.5 US gal/min
Pump flow 60Hz
102 l/min; 27 US gal/min

Power system

Power technology
SmartPower™
Electric motor type
ABB
Power*
27.5 kW
Recommended fuse size*
63 A
Starting device
Soft start/Direct start

Control system

Control type
SmartRemote™, portable
Signal code
Digital
Transfer
Professional radio/Cable
Range, radio
Up to 300 m

Weight

Machine weight**
2 100 kg; 4 630 lbs
Recommended max. attachment weight
350 kg; 772 lbs

Noise level

Sound power level LWA***
87 dB(A)

Width min.
780 mm; 30.7 in
Height min.
1351 mm; 53.2 in
Vertical reach (incl. breaker)
5450 mm; 215 in
Horizontal reach (incl. breaker)
5100 mm; 201 in

*Valid for 400V/50Hz and 440V/60Hz
**Excluding options and attachment
***Measured according to directive 2000/14/EC, excl. attachment

Extra cylinder protection

Extra cylinder protection

Suitable for hot environments, act as heat- and impact protection.

Download PDF
Rubber caterpillar tracks

Rubber caterpillar tracks

An allround solution with great grip.

Steel caterpillar tracks

Steel caterpillar tracks

Suitable when operating in hot or sharp material.

Download PDF
Heat resistant hoses

Heat resistant hoses

Suitable for red hot applications.

Download PDF
Forced draft cooling of machine

Forced draft cooling of machine

Suitable for high ambient temperatures. Flushes cool air into electrical cabinet and cooler.

Download PDF
Forced draft cooling for breaker

Forced draft cooling for breaker

Suitable for red hot applications and flushes air through the breaker.

Download PDF
Steel pads

Steel pads

Suitable when machine is placed on very hot ground.

Download PDF
Waterspray

Waterspray

Sprays water when breaker is activated and binds dust efficiently.

Download PDF
Atomized Water Mist

Atomized Water Mist

A unique and integrated system that tackles the most hazardous silica dust particles.

Download PDF
Airflushing for breaker

Airflushing for breaker

Airflushing prevents dust from entering breaker, especially useful for upwards breaking and a must for underwater use.

Extra hydraulic function

Extra hydraulic function

Required for certain tools only.

Download PDF
Counterweight

Counterweight

Allows the use of extra heavy tools.

Download PDF
Lifting eyes

Lifting eyes

Dedicated lifting eyes for easy connection. (Regular lifting points standard on all machines.)

Download PDF
Motion Warning

Motion Warning

Motion warning for traveling machine, with visual and audible indication.

Breakers

Brokk’s hydraulic breakers are the most versatile and effective attachments for your Brokk robot.

Concrete crushers

A concrete crusher allows you to do silent demolition with less noise, dust and vibration.

Metal shears

Our wide range of metal shears allows you to cut steel of many different sizes.

Buckets

Turn your Brokk robot into a flexible excavator, optimal for confined spaces

Clamshell buckets

Brokk’s wide range of clamshell buckets transforms your Brokk robot into the perfect machine for sorting material and debris

Multi Purpose Grapples

Make your work even more efficient with a multi purpose grapple from Brokk, the ideal attachment for loading, sorting and separating debris

Sorting & demolition grapples

Sorting and demolition grapples are tailor-made and ideal for soft demolition and stripping structures inside of buildings

Planers

Brokk planers remove concrete, paint, asbestos or other layers in a controlled manner up to a certain depth

Drilling

Drill holes in rock, concrete, or compact soil in open or limited spaces.

Drum cutters

Brokk drum cutters are designed for trenching, demolition and concrete surfaces

Shotcrete

This attachment can turn your Brokk robot into a shotcrete machine for confined spaces

Cut off saw

Replace hand-held equipment with a Brokk cut off saw

Side angling device

Give your Brokk hydraulic breaker that extra angle for extremely confined spaces
